Horizontal scroller: 1,000,000 cards, the vertical class sideways

This is not a second scroller. It is the vertical 1M scroller — the same tuned class, with the same prefix-sum cursor, origin rebasing, creep integrator and seek pipeline — subclassed through its eight axis seams. Every place the base class touches a DOM dimension or a gesture axis is a protected getter or method; the subclass overrides exactly those — each one carrying the override keyword, which TypeScript's noImplicitOverride option makes mandatory, so a seam can never be overridden silently or orphaned by a base rename — and the hand-tuned 80% runs sideways, unchanged. This one subclass powers three shipped surfaces: the card strip above, the home page's blog drip, and — composed with a pure text chunker — a ~400k-character book scrolling as one line. The full story is in Ship the variant, keep the tuning.

The reference for the module standard

HorizontalVirtualScroller.ts doubles as the canonical shape of an ivue module. A class file has exactly three residents — imports, the class, and the namespace — and the contract lives ON THE CLASS:

• Contract — static getters: propsTypes, propsDefaults, the fused props (via propsWithDefaults, reading through the receiver), emits. Being statics is what lets a subclass compose its surface with super — every prop inherited, one default overridden, with the reason on the line — and what makes the contract swap together with Class.

• Identity — $Class (raw, for children to extend), Class (Reactive(), for you to new), Instance (the unwrapping-surface type).

• Types — all derived from the class (Props, Emits, Slots, Exposed), never hand-duplicated.

• Generic typing — the part that makes this the FULL canonical example: the scroller is a generic component (<T extends VirtualScroller.BaseItem>), and the namespace pattern carries the generic through every layer TS makes awkward. Reactive() returns the same constructor, but its return type cannot carry <T> (TypeScript has no higher-kinded types), so Class is cast back to the raw constructor type to keep new VirtualScroller.Class<T>() fully generic, and Instance<T> applies ReactiveInstance by hand. A runtime props map cannot carry a type parameter either, so Props<T> grafts it back over the one prop that needs it: Omit<ExtractPropTypes<typeof $Class.props>, 'modelValue'> & { modelValue: T[] }. Exposed<T> closes the loop for template refs.

The SFC is pure wiring against that contract — and generic wiring: <script setup generic="T extends VirtualScroller.BaseItem"> hands the runtime props object to defineProps through Class (no compiler macro ever resolves a cross-file type) and one cast recovers the precision the runtime map cannot carry:

const props = defineProps(
  VirtualScroller.Class.props
) as unknown as VirtualScroller.Props<T>;

The state destructure is the only other thing in <script setup>.

Related guide pages

• Inheritance & super — extends $Class, super, override.
• Extensible Components — props, emits and slots that extend with the class.
• Performance by Design — what the shape costs and does not.

The source

The subclass first — the two files that ARE the horizontal scroller — then the base machinery they inherit, exactly as running above:

Loading…

The strip's spec asserts every seam names the x axis; the marquee's two specs prove the chunker as a pure Static class and the marquee as composition. They are on their own page — Horizontal Scroller: Specs & Contract — and the method is on Testing & Invariants.

The example model is docs code — and it is written to the same standard the page teaches: one class, one namespace, the million-card builder and its caption bank living inside the namespace (the captions un-exported, private to the file).

What to notice

• Cards in the DOM stays at the window size across a million cards — and every card has a different natural width (the caption decides it), so the width map is genuinely measured, not assumed.
• A plain vertical wheel scrolls the page. The strip obeys deltaX only — shift+wheel and horizontal trackpad swipes drive it. A horizontal element that hijacks vertical scrolling is how you make readers hate a page.
• The bar under the cards drags in progress space — the thumb renders position / (extent − container), and its drag is the exact inverse, so it lands where it points, including the true end.
• Text selection walks sideways too. The selection is a range over the data (the vertical page explains it), and the only thing that changes here is the axis: the nearest-card and edge-distance math run along x, and a drag past the left or right edge autoscrolls the strip. One seam, selectionAxis, is all the subclass overrides. The marquee above the vertical list is the same class and joins its chunks with a space instead of a line break (selection-join).
• The glide hands off, both ways. A forward flick decays to the glide speed and the creep adopts the scroll at that exact speed — it never stalls to zero and restarts. The slider changes speed mid-glide; the integrator reads the live value every frame.

Wheel through a million cards above, then read the two files that made it possible — that ratio is the page's whole argument.
